Environment and Reliability | RG-CS83-24GT4XS | RG-CS83-48GT4XS | RG-CS83-12GT4XS-P | RG-CS83-24GT4XS-P | RG-CS83-48GT4XS-P |
Temperature | Operating temperature: 0°C to 45°C (32°F to 113°F) Storage temperature: –40°C to +70°C (–40°F to +158°F) |
Humidity | Operating humidity: 10% to 90% RH (non-condensing) Storage humidity: 5% to 95% RH (non-condensing) |
Altitude | Operating altitude: 0 m to 5,000 m (0 ft. to 16,404.20 ft.) Storage altitude: 0 m to 5,000 m (0 ft. to 16,404.20 ft.) |
Mean time between failure (MTBF) | 207,962 hours (about 23 years) | 208,926 hours (about 23 years) | 211,466 hours (about 24 years) | 209,714 hours (about 23 years) | 200,253 hours (about 22 years) |
Fan | No fan | 1 x fixed fan module | 1 x fixed fan module | 1 x fixed fan module | 1 x fixed fan module |
Heat dissipation | Fanless design, natural heat dissipation | Front-to-right and left-to-right airflow |
Acoustic noise | Fanless, quiet, < 20 dB | 27℃ (80.6°F): 32 dB | 27℃ (80.6°F): 35 dB | 27℃ (80.6°F): 32 dB | 27℃ (80.6°F): 35 dB |
Cable hot swapping | Cable hot swapping for all ports |
Fan monitoring | Fanless design | PID-based multi-level speed adjustment Fan speed control (manual configuration not supported) Fan failure alarming | PID-based multi-level speed adjustment Fan speed control (manual configuration not supported) Fan failure alarming | PID-based multi-level speed adjustment Fan speed control (manual configuration not supported) Fan failure alarming | PID-based multi-level speed adjustment Fan speed control (manual configuration not supported) Fan failure alarming |
Temperature monitoring | Supported | Supported | Supported | Supported | Supported |
ESD | ESD contact/air discharge: 6 kV/8 kV ESD susceptibility contact/air discharge: 8 kV/15 kV |
Surge protection | Power port: common mode 6 kV, differential mode 6 kV Communication port: 10 kV | Power port: common mode 6 kV, differential mode 6 kV Communication port: 10 kV | Power port: common mode 6 kV, differential mode 8 kV Communication port: 10 kV | Power port: common mode 6 kV, differential mode 8 kV Communication port: 10 kV | Power port: common mode 6 kV, differential mode 8 kV Communication port: 10 kV |
Conformal coating | Conformal coating supported (key components only) |
